Cáp Kết Nối Balluff BKS-S 33M-05

Cáp Kết Nối Balluff BKS-S 33M-05

Model: BKS-S 33M-05

Other name: CABLE & CONNECTOR

Thông số kỹ thuật Cáp Kết Nối Balluff BKS-S 33M-05

M16x0.75-Female,8-pole

Cable PUR Shielded black, 5.00m,

Drag chain compatible

Connector 01, versionangled

Cable temperature, fixed routing-50…80 ℃

Operating voltage Ub60 VDC/60 VAC

IP rating: IP67

Electrical connection

Bending radius min., fixed cable 5 x D

Bending radius min., flexible cable 10 x D

Cable PUR Shielded black, 5.00 m,

Drag chain compatible

Cable diameter D 6.00 mm ±0.15 mm

Cable, bending cycles min. 2 million

Conductor cross-section 0.25 mm²

Connector 01, version angled

Number of conductors 8

Number of pins 8

System assembled

Electrical data

Conductor construction 4×2 twisted-pair

Operating voltage Ub 60 VDC / 60 VAC

Rated current (40 °C) 5.0 A

Environmental conditions

Cable temperature, drag chain -25…60 °C

Cable temperature, fixed routing -50…80 °C

Cable temperature, flexible routing -25…80 °C

IP rating IP67

Material

Cable jacket, material PUR

Jacket material, note Shielded

Material contact carrier PBT

Material contacts Bronze

Material cover nut Brass

Material grip Die-cast zinc

Mechanical data

Acceleration max., drag chain 5 m/s²

Cable jacket, color black

Cable length 5.00 m

Cable properties Drag chain compatible

Horizontal travel permitted, drag chain 5 m

Tightening torque pigtail 0.6 Nm

Traverse speed max., drag chain 200 m/min

Vertical travel permitted, drag chain 2 m

Remarks

Enclosure rating per IEC 60529, only in screwed state with the associated mating piece.

Cable construction acc. to UL-AWM Style 20549

Halogen-free per DIN VDE 0472 Part 815

Silicone-free

Flame resistance per UL FT2
